The Modular Game Engine
A modular native C++ game engine built for fast workflows, integrated tooling, and hot-compiled ModuCPP scripting.
System Requirements
Modularity compiles for baseline x86-64, no AVX required, so it runs on low-power hardware most engines have dropped. On weaker machines it will offer to tune graphical effects, but only if you agree first.
Minimum to Play
- OS
- Windows 10 64-bit, or Linux (64-bit x86)
- Processor
- Any 64-bit x86 CPU, no AVX required
- Memory
- 2 GB RAM
- Graphics
- OpenGL 3.3 core profile
- Storage
- Varies by game
Minimum to Develop
- OS
- Windows 10 64-bit, or Linux (64-bit x86)
- Processor
- Any 64-bit x86 CPU (compiles will be slow)
- Memory
- 4 GB RAM
- Graphics
- OpenGL 3.3 core profile
- Storage
- 16 GB, plus a C++ toolchain (~32 GB total on Windows)
- Display
- 1366 × 768
- Additional Notes
- Requires a C++ toolchain (MSVC Build Tools on Windows, build-essential/base-devel on Linux)
Recommended
- OS
- Windows 10/11 64-bit, or Linux (64-bit x86)
- Processor
- Intel Core i5-8600K / AMD Ryzen 5 3600 or better
- Memory
- 8–16 GB RAM
- Graphics
- Discrete GPU recommended for 3D
- Storage
- 128 GB+ SSD
- Display
- 1920 × 1080
Platform Support
- Desktop
- Windows and Linux, 64-bit x86
- Mobile
- Android export via OpenGL ES 3.0
- macOS
- No macOS build available
Choose Your Scripting Surface
All four options can drive the same 2D movement test. The difference is how much engine plumbing each layer exposes to the script author.
High-level gameplay scripting with built-in helpers.
Movement2DTest.mcpp
ModuCPP
| 1 | add ModuCPP; |
| 2 | add ModuInput; |
| 3 | add ModuEngine; |
| 4 | |
| 5 | public class Movement2DTest : ModuNode |
| 6 | { |
| 7 | public float walkSpeed = 4.0f; |
| 8 | public float runSpeed = 7.0f; |
| 9 | public float acceleration = 18.0f; |
| 10 | public float drag = 8.0f; |
| 11 | |
| 12 | void TickUpdate() |
| 13 | { |
| 14 | Vector2 move = input.WASDNormalized(); |
| 15 | bool running = input.sprint(); |
| 16 | float speed = running ? runSpeed : walkSpeed; |
| 17 | |
| 18 | TryMoveRigidbody2D(ctx, move * speed, acceleration, drag, dt); |
| 19 | obj.UILabel = "ModuCPP 2D Speed: " + IntR(speed); |
| 20 | } |
| 21 | } |
Movement2DTest.cpp
C++
| 1 | #include "ModuCPP" |
| 2 | #include <cmath> |
| 3 | #include <string> |
| 4 | |
| 5 | namespace { |
| 6 | float walkSpeed = 4.0f; |
| 7 | float runSpeed = 7.0f; |
| 8 | } |
| 9 | |
| 10 | void TickUpdate(ScriptContext& ctx, float dt) |
| 11 | { |
| 12 | if (!ctx.object || dt <= 0.0f || !ctx.HasRigidbody2D()) return; |
| 13 | |
| 14 | glm::vec3 move3 = ctx.GetMoveInputWASD(0.0f, 0.0f); |
| 15 | glm::vec2 move(move3.x, move3.z); |
| 16 | |
| 17 | const float len = glm::length(move); |
| 18 | if (len > 0.0001f) { |
| 19 | move /= len; |
| 20 | } |
| 21 | |
| 22 | const float speed = ctx.IsSprintDown() ? runSpeed : walkSpeed; |
| 23 | ctx.SetRigidbody2DVelocity(move * speed); |
| 24 | ctx.SetUILabel(std::string("Native C++ 2D Speed: ") + ModuCPP::IntR(speed)); |
| 25 | } |
movement_2d.mko
MAKO
| 1 | using ModuMAKO; |
| 2 | using ModuEngine; |
| 3 | script "MovementThingy" : ModuNode; |
| 4 | Begin() { |
| 5 | EnsureRigidbody(true, false); |
| 6 | EnsureCapsuleCollider(1.8, 0.4); |
| 7 | settings = StandaloneMovementSettings(); |
| 8 | state = StandaloneMovementState(); |
| 9 | debug = StandaloneMovementDebug(); |
| 10 | |
| 11 | # Gravity stuff |
| 12 | for i in range(120) {TickStandaloneMovement(state, settings, 1 / 60, debug); } |
| 13 | AddLog("settled at y=" + obj.position.y, Type.Info); |
| 14 | assert(debug.grounded, "character reports grounded once settled"); |
| 15 | |
| 16 | # Movement stuff |
| 17 | start_x = obj.position.x; |
| 18 | state.localVelocity = Vector3(1, 0, 0) * settings.moveTuning.walkSpeed; |
| 19 | for i in range(60) {TickStandaloneMovement(state, settings, 1 / 60, debug);} |
| 20 | AddLog("moved to x=" + obj.position.x, Type.Info); |
| 21 | |
| 22 | # Jumping stuff |
| 23 | jumped = AddRigidbodyImpulse(Vector3(0, settings.locomotionTuning.jumpImpulse, 0)); |
| 24 | assert(jumped, "jump succeeds while grounded"); |
| 25 | TickStandaloneMovement(state, settings, 1 / 60, debug); |
| 26 | assert(debug.velocity.y > 0, "jump gives positive vertical velocity"); |
| 27 | assert(!debug.grounded, "character leaves the ground immediately after a jump"); |
| 28 | } |
movement_2d_test.c
C
| 1 | #include "ScriptRuntimeCAPI.h" |
| 2 | #include <math.h> |
| 3 | |
| 4 | static float g_walkSpeed = 4.0f; |
| 5 | static float g_runSpeed = 7.0f; |
| 6 | |
| 7 | void Modu_Begin(ModuScriptContext* ctx) { |
| 8 | if (!ctx) return; |
| 9 | Modu_AddConsoleMessage(ctx, "C bridge 2D movement test ready.", MODU_CONSOLE_INFO); |
| 10 | } |
| 11 | |
| 12 | void Modu_TickUpdate(ModuScriptContext* ctx, float dt) { |
| 13 | if (!ctx || dt <= 0.0f) return; |
| 14 | |
| 15 | ModuVec3 move = Modu_GetMoveInputWASD(ctx, 0.0f, 0.0f); |
| 16 | float len = sqrtf((move.x * move.x) + (move.z * move.z)); |
| 17 | if (len > 0.0001f) { |
| 18 | move.x /= len; |
| 19 | move.z /= len; |
| 20 | } else { |
| 21 | move.x = 0.0f; |
| 22 | move.z = 0.0f; |
| 23 | } |
| 24 | |
| 25 | float speed = Modu_IsSprintDown(ctx) ? g_runSpeed : g_walkSpeed; |
| 26 | ModuVec3 pos = Modu_GetPosition(ctx); |
| 27 | pos.x += move.x * speed * dt; |
| 28 | pos.z += move.z * speed * dt; |
| 29 | Modu_SetPosition(ctx, pos); |
| 30 | } |
